Common specifications of transparent sound barrier:
Screen size: 500mm * 2000mm, 500mm * 3000mm, etc. can be customized.
The thickness of galvanized sheet of single panel: 0.6mm, 0.7mm, 0.8mm, 1.0mm, 1.2mm, etc. can be customized.
Total thickness of screen: 80mm, 100mm, etc. can be customized.
Column: H-shaped steel 100mm * 100mm * 6 * 8mm, 125mm * 125mm * 7 * 10mm, etc. can be customized.
Height: 3M, 3.5m, 4m, 4.5m, 5m, 5.5m, 6m, etc. can be customized.
Style: blind hole sound barrier, micro hole sound barrier, vertical sound barrier, top corner type sound barrier, top arc sound barrier, overall arc sound barrier, transparent sound barrier, concave convex through hole sound barrier, etc.
Material: aluminum plate sound barrier, metal sound barrier, color steel sound barrier, glass sound barrier, PC plate sound barrier, etc.
Color: dark grey, light grey, white, green, blue, etc. can be customized.
Surface treatment: galvanized + sprayed.
Stability: increase diagonal bracing.
The main components of transparent combined sound barrier: foundation, column, screen body, fastener, seal, and some also include the top structure.
1) Transparent combined sound barrier screen: galvanized plate, back plate, keel, glass wool, DuPont film, front punching rate more than 25%;
2) Transparent combined sound barrier column: H-shaped steel, flange chassis, diagonal brace, inner rib plate, outer rib plate;
Characteristics of transparent combined sound barrier:
1. Frame: made of oxidized aluminum alloy, it has the characteristics of light weight, high strength, no corrosion, beautiful appearance, etc.
2. Good light transmittance: polycarbonate board (also known as PC board) is mostly used for transparent part, with light transmittance of more than 85%, which is equivalent to glass. It is colorless, transparent, heat-resistant, impact resistant, flame-retardant, high conversion rate, good processing performance, rigid and tough, with good dimensional stability.
3. The transparent composite plate has low water absorption, little change in use scale in enriched environment and excellent heat resistance. It can be used for a long time at 130 ℃ high temperature. It also has good cold resistance and is not easy to crack at - 180 ℃.
4. Impact resistance: the impact strength is 250-300 times that of ordinary glass, 30 times that of acrylic plate of the same thickness, and there is no crack when it is dropped two meters below the 3kg hammer.
5. UV protection: the surface of the product has a UV resistant co extrusion layer, which can prevent the UV from passing through. It is more suitable for protecting precious works of art and exhibits from UV damage.
6. Sound insulation performance: transparent board sound barrier has obvious sound insulation effect, better sound insulation than glass and sub afterburner of the same thickness, and is the material of transparent board sound barrier.
7. Energy saving: cool in summer, heat preservation in winter, heat insulation effect is 7% - 25% higher than the same glass.
8. Temperature adaptability: PC board does not have cold embrittlement at - 100 ℃, does not soften at 135 ℃, and has no obvious change in mechanical and mechanical properties in harsh environment.
